| Model Version |
WR3000 1.0 |
| Hardware Specs |
|
| CPU Chipset |
MT7981 |
| CPU Details |
1.3 GHz Dual-Core, ARM Cortex-A53 |
| Flash/ROM |
16 MB (128 Mbit) NOR |
| DDR/RAM |
256 MB (2 Gbit) DDR3 |
| 5 GHz Wi-Fi Speed |
2402 Mbps |
| 2.4 GHz Wi-Fi Speed |
574 Mbps |
| 5 GHz Wi-Fi Streams |
3T3R (3×3 MIMO) |
| 2.4 GHz Wi-Fi Streams |
2T2R (2×2 MIMO) |
| Wi-Fi Antennas |
4× Fixed |
| 5 GHz Antenna Gain Max |
4.8dBi |
| 2.4 GHz Antenna Gain Max |
3.4dBi |
| 5 GHz FEM/PA/LNA |
3× Internal |
| 2.4 GHz FEM/PA/LNA |
2× Internal |
| Beamforming |
True |
| Max Range Performance |
200 m (656 ft) |
| Indoor Wall Performance |
2 wooden walls |
| Gigabit RJ45 Ports |
4 (1 WAN, 3 LAN) |
| LED Indicators |
System, Internet, WAN, LAN, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi |
| Physical Buttons |
WPS Button, Reset Button |
| Power Input |
DC Jack |
| Power Methods |
DC 12V 1A |
| Power Adapter Input |
100 ~ 240 V, 50/60 Hz AC |
| Power Adapter Output |
12V 1A DC |
| Max Power Consumption |
7.5W |
| Operating Temperature |
0 ℃ ~ 40 ℃ (32 ℉ ~ 104 ℉) |
| Storage Temperature |
-40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) |
| Operating Humidity |
10% ~ 90% non-condensing |
| Storage Humidity |
5% ~ 95% non-condensing |
| Certifications |
FCC, CE |
| Installation |
Desktop, Wall-mount |
| Dimensions |
183.3×109×35 mm (7.22×4.29×1.38 inches) |
| Product Weight |
295 g (10.41 oz.) |
| Package Content |
WR3000, Power Adapter, Ethernet Cable, Installation Guide |
| Retail Package Weight |
BR: 589 g; EU: 614 g; UK: 626 g; US: 615 g |
| Retail Package Dimensions |
240×230×60 mm (9.45×9.06×2.36 inches) |
| Units per Carton |
20 |
| Carton Dimension |
49.5×32.5×48 cm (19.49×12.8×18.9 inches) |
| Carton Gross Weight |
BR: 12.9 kg; EU: 13.5 kg; UK: 13.6 kg; US: 13.1 kg |
| Carton Net Weight |
BR: 11.8 kg; EU: 12.3 kg; UK: 12.5 kg; US: 12.3 kg |
| Software Specs |
|
| Wi-Fi Standards |
Wi-Fi 6 |
| Max Wi-Fi Modulation |
1024-QAM |
| Wi-Fi Efficiency |
OFDMA, MU-MIMO, BSS Color |
| Max Capacity |
512 |
| Recommended Client Upper Limit |
200 |
| Max Wi-Fi Channel Width |
160 MHz |
| Wi-Fi Security |
WPA/WPA2/WPA3 |
| Guest Network |
2.4 GHz, 5 GHz |
| WPS |
True |
| Operation Modes |
Wi-Fi Router, Access Point, Range Extender, WISP, Client, Mesh (Cudy Mesh) |
| Mesh Backhaul |
Wireless Backhaul, Wired Backhaul, Multi-Band Backhaul |
| WAN Mode |
DHCP, Static IP, PPPoE |
| Internet Failover Sequence |
WAN, WISP |
| QoS |
Per-User Rate Limiting |
| DHCP Features |
Address Reservation, DHCP Client List, Server |
| IP Versions |
IPv4/IPv6 |
| IPv6 Protocols |
Relay, Dynamic (SLAAC/DHCPv6), Static (Fixed IP), Passthrough, 464XLAT, MAP-E, DS-Lite |
| IPTV/VLAN |
Bridge, Tag VLAN |
| TTL Customization |
Extend, Spoof, Custom |
| IGMP Features |
IGMP Proxy, IGMP Snooping |
| Port Forwarding Features |
Port Forwarding, Port Triggering, UPnP, DMZ |
| Firewall Features |
SPI Firewall, DoS Protection, Block PING |
| Application Layer Gateway |
IPSec, L2TP, PPTP, FTP, TFTP, H323, SIP, RTSP Passthrough |
| VPN Server |
WireGuard, OpenVPN, PPTP, L2TP |
| VPN Client |
WireGuard, OpenVPN, PPTP, L2TP |
| VPN Performance |
OpenVPN Client (UL/DL): 90 / 120 Mbps
OpenVPN Server (UL/DL): 180 / 160 Mbps
WireGuard Client (UL/DL): 224 / 230 Mbps
WireGuard Server (UL/DL): 160 / 90 Mbps |
| DNS Options |
DNS over TLS, Manual DNS, Rebind Protection, Override Clients’ DNS |
| DNS over TLS Providers |
Cloudflare, Google, Quad9, Custom |
| Captive Portal |
True |
| Wake on LAN |
True |
| Online Detection |
True |
| Max Concurrent VPN Tunnels |
Not specified |
| Management Features |
Wi-Fi Time Schedule, MAC Filter, IP/MAC Binding |
| Per-Devices Management |
Internet On/Off, VPN On/Off, Online Time Schedule, Device Rename |
| Content Management |
Domain Filter, IP Filter |
| System Control Methods |
Config Web Page, App Control |
| Remote Control Methods |
Config Page via HTTPS, App Control, TR069/TR098/TR111/TR181 |
| Firmware Upgrade |
Local Update, App (Over the Air), Online Update |
| Reliability Features |
Timed Reboot, Backup and Restore |
| Diagnostic Tools |
Diagnosis, Ping, Traceroute, NSLookup, System Log |
| Languages Supported |
English, Bengali, Catalan, Czech, German, Greek, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Japanese, Khmer, Korean, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Swedish, Thai, Turkish, Ukrainian, Vietnamese, Simplified Chinese, Traditional Chinese |
| Dashboard Panel |
Internet Status, Mesh Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version |
| Charts |
Mesh Topology, Internet Speed, WISP Speed, Wi-Fi Speed |
